Functions and Features
1. Functions of dust removal, UV printing, pre-curing and main curing.
2. Full servo control feeding platform, constantly tension control system, with large roller, ensure the RFID tag feeding process 100% no damage.
3. The patented printhead structure can install multiple-printhead with no spacing, support full page printing.
4. The system supports minimum 2 LB font HD printing.
Technical Specification
|
Printing Speed
|
40—80 m/min
|
|
Printing Resolution
|
Printhead direction:600DPI, motional direction:300 - 1200DPI adjustable
|
|
Printing Width
|
108 mm extensible
|
|
Printing Color
|
Monochrome, Customized color, Multiple color
|
|
Suitable Printing Material
|
Copper paper plate, semi-copper plate, part of wool fabric and gloss, PVC, PP, PE, etc.
|
|
Printing Content
|
Support variable one-dimensional code and QR code, batch images and PDF documents.
|
|
Optional Functions
|
Visual detection, freeze picture, error label marking, dust removal,anti-static,corona,Reading TID before printing
|
|
Power
|
AC220-240V 50HZ 2KW
|
|
Equipment Size
|
(L)2200*(W)1050*(H)1700mm
|
|
